Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable

  • 1
  • 2
  • 3

MOQ : 1

Price : 1000

Place of Origin : Chnia

Brand Name : Sansion

Certification : CE SGS ISO9001

Packaging Details : plywood case

Payment Terms : TT LC

Model NO. : SXTC

Max Diameter of Workpiece : 900mm

Mass Scope of Workpiece : 900kg

Type : Strength Testing Machine

Maxcapacity : >1000KN

Accuracy Grade : 0.5

Load Way : Electronic Load

Loading Method : Static Load

Display : Needle

Control : Manual Control

Weight : 0-100Kg

Power Source : AC380V

Oil Cylinder Position : Under

Key Testing1 : Dielectric Withstand Voltage Test

Key Testing2 : Insulation Integrity Verification

Key Testing3 : Leakage Current Monitoring

Key Testing4 : Step Voltage Test

Transport Package : Plywood Case

Specification : Customized

Trademark : Sansion

Origin : China

HS Code : 9030339000

Production Capacity : 200 Units/Month

Contact Now

Product Description
AC DC Hipot Test Set Power Frequency Withstand Voltage Test Set For Dielectric Strength Test
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
General Information:
SXTC Series Power Frequency Withstand Voltage Test Set is suitable for measuring Dielectric Withstand voltage test, it includeds 1 manual controller and 1 test transformer (Dry/oil/gas/ultra light/insulated/no partial discharge type).
It has superior performance,functionality and access to reliable,pleasing in appearance,easy operation and maintenance.
1: Features:
1.HV bushing was first time made
2.Between the bushing and the gas tank is completely isolated, and all connection parts adopted imported "O" type sealing ring seal, so we completely solve the common problems of transformer leakage.
3.Sleeping core type design, effectively improve seismic resistance.
4.All products're passed through 1.1 times induction withstand voltage testing.
5.Pure SF6 insulating medium.
6. HV & LV cables are made by high strength polyester, oxygen free copper enameled wires.
7.The core was adopted with new WISCO,two silicon cold rolled silicon steel strip .
2. Specifications:
√ Input voltage: AC 220(380)V (customized)
√ LV output: AC 0-250(430)V
√ LV current: 0-5/10/15/50A (customized)
√ Output capacity: 0-3/5/10/15 kVA (customized)
√ HV output: 0-50/100/150/200 kV (customized)
√ HV current: 0-50/100/150/200/500/1000/2000mA (customized)
√ Timing range: 0-9999S
√ Working temperature: -20ºC to 50ºC
√ Voltage precision: ≤1.5% ±1 digit (F.S)
√ Current precision: ≤1.5% ±1digit (F.S)
3: Main parameters of SXTC-M Control Unit:
Model

Input Voltage (V)
Capacity (KVA)
Rated Output
HV voltmeter
KV/V
Oversize
m3(L×W×H)
Voltage (V)
Current (A)
SXTC-M05
220
0.5
200
2.5
50/100
20×30×20
SXTC-M15
220
1.5
200
7.5
50/100
26×36×24
SXTC-M3
220
3
200
15
50/100
26×42×24
SXTC-M5
220
5
200
25
50/100
60×45×37
SXTC-M6
220
6
200
30
50/100
53×40×60
SXTC-M10
220
10
200
50/25
(50/100)/100
53×40×65
SXTC-M15
380
15
400
37.5
(50/100/150)/100
53×40×70
SXTC-M20
380
20
400
50
(50/100/150)/100
53×43×84
SXTC-M25
380
25
400
62.5
(50/100/150)/100
53×45×90
SXTC-M30
380
30
400
67.5
(50/100/150)/100
65×55×115
SXTC-M40
380
40
400
100
(50/100/150)/100
70×60×115
SXTC-M50
380
50
400
125
(50/100/150)/100
70×60×115
Company Profile
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
About Sansion
Sansion Power Electric was established in 2005, a technocrat who have rich experience of more than 20 years in R&D, manufacturing and marketing of power electrical testing products, which are widely used in the fields of power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace and etc.
Sansion Power Electric contains R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, general office, sales departments, information office and ete, now we have more than 80 employees including 20 technical engineers. We have obtained the IS09001 quality system certification and all products strictly conform to theinternational lEC and Chinese state standards.
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
Certifications
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
Packing & Delivery
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
Customer Visit
Power Frequency Dielectric Withstand Tester AC DC Hipot Test Set Customizable
FAQ
Q1: Is your company a sales company or a manufacturer?
A: Sansion Power Electric Co., Ltd. is an industrial and trade enterprise, with its own factory, self-produced and self-sold. We were founded in 2005 and have twenty years of production experience. Our company has reliable production lines, test rooms and R&D centers.

Q2: Whether the goods are in stock, whether they can be customized, and how long the delivery time is?
A: After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.
Q3: Is the quality guaranteed?
A: In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.
Q4: What are the after-sales terms?
A: What are the after-sales terms?
We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.
Q5: What are the cooperative countries or regions?
A: Products have been successfully exported to the United States, French ,Brazil, Australia, Spain, Portugal , Oman ,Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries and regions.
